Dropbox

download Download CloverDX Library (clib)

This library contains components for interaction with Dropbox.

Description

The library supports the following operations:

  • Upload file to Dropbox
  • List Dropbox folder
  • Purge Dropbox folder
  • Get Dropbox download link
Properties
Author
CloverDX
Library version
1.0
Label
Dropbox
Compatible
CloverDX 5.15 and newer
Tags
connector reader writer file-manipulation cloud-storage dropbox

Common parameters

All parameters can be set via component parameters. Parameters that have a corresponding metadata field can also be set via record. Parameter values sent via record have priority.
Common parameters are displayed in Security and Advanced sections of the component.

Parameter label Description Required Default Value Metadata Field
OAuth2 connection URL of OAuth2 connection to be used for connecting to the Dropbox true
API URL URL of the Dropbox API true https://api.Dropboxapi.com/2
Content API URL URL of the Dropbox content API true https://content.Dropboxapi.com/2
Retry count Retry count for upload file to dropbox true 3
Date format Format of timestamps used in the API calls true yyyy-MM-dd'T'H:m:s'Z'

Components

Below is a description of each component included in the library.

UploadFileToDropbox

This component uploads a file to specified Dropbox folder. It can also generate a download link for the uploaded file.

Parameters

Parameter label Description Required Default Value Metadata Field
Source path Path to the local file to be uploaded. true sourceFileUrl
Write mode Selects what to do if the file already exists.
Allowed values: add,overwrite,update.		 false add writeMode
Target path Path in the user's Dropbox to save the file.
Format: /directory/directory/file		 true targetFileUrl
Autorename If there's a conflict, as determined by mode, have the Dropbox server try to autorename the file to avoid conflict. false false autorename
Mute Normally, users are made aware of any file modifications in their Dropbox account via notifications in the client software.
If true, this tells the clients that this modification shouldn't result in a user notification.		 false false mute
Generate download link set to true if a download link should be generated. false true getLink
Link expiration days Expiration of the generated Download links. If set to 0, link will not expire.
Usage of this feature is limited only for accounts with Dropbox Professional plan and upwards.		 false 30
Upload session threshold Size limit (in bytes) for using upload session instead of uploading the file in single request. false 1000000
Chunk size Max file size (in bytes) to upload with single request.
Dropbox limit is 130MB.		 false 500000
Set password Set to true if the download link should be password protected. false false setPassword
Link password Password that will be set for the download link.
If empty and "Set password" is true, random password will be generated.		 false linkPassword

ListDropboxFolder

This component returns a list of files/folders present in the specified Dropbox path.

Parameters

Parameter label Description Required Default Value Metadata Field
List path Path to the folder to list. Leave empty for root path. true listPath
Recursive Enables recursive search true false recursive

PurgeDropboxFolder

This component deletes files from the specified Dropbox path.

Parameters

Parameter label Description Required Default Value Metadata Field
Purge path Path to directory to be purged. true purgePath
File age in days Specifies the number of days since the file was last modified to delete it.
If set to 0 all files will be deleted.		 true 3
Expired only If enabled, only files with no or expired download links will be deleted true false
Recursive Set to true if the purge should be recursive. true false recursive

GetDropboxDownloadLink

This component creates new or updates existing download link for Dropbox file. Password and expiration can be set for the generated links.
Note: Usage of this component is limited only for accounts with Dropbox Professional plan and upwards.

Parameters

Parameter label Description Required Default Value Metadata Field
File path Path to Dropbox file to get the link for. true filePath
Password length Length of the auto-generated password false 10
Link expiration days Expiration of the generated Download links. If set to 0, the link will not expire. false 30
Set password Set to true is the download link should be password protected. true false setPassword
Link password Password that will be set for the download link.
If empty and "Set password" is true, a random password will be generated.		 false linkPassword

DownloadFileFromDropBox

This component downloads a file (or a folder as a .zip) from specified Dropbox path.

Parameters

Parameter label Description Required Default Value Metadata Field
File path Path to Dropbox file/folder to be downloaded. true filePath
Target direcrory Path to directory where the downloaded file will be stored. true targetDir
Zip Enable if the target path is a folder and should be downloaded as a .zip. true false zip
Keep original order Make sure the records are sorted the same way on input an output ports.
When enabled, all files have to be downloaded before any records are sent to output port.		 false false

Online installation (Server connected to Internet)

  1. In Server Console, navigate to Libraries > Install library from repository
  2. Select Library Repository dropdown > CloverDX Marketplace
  3. Check the box next to the libraries you want to install (if there are any dependencies, you can install all of them once - see Requirements above)
  4. Click Install

Offline installation (Server without Internet connection)

  1. Download all the libraries you need from the CloverDX Marketplace (including dependencies, see Requirements above). You should get a ".clib" file for each library
  2. Transfer the ".clib" file(s) to your offline Server machine (USB stick, ...)
  3. In Server Console, navigate to Libraries > Install library from repository > Down arrow for more options > Browse local files...
  4. Select the downloaded .clib files on your disk and install

Configuration

Watch this video to learn how to set up OAuth2 for use in CloverDX Libraries.
